Pre Engineered Building Components: Types, Uses and Functions
Pre engineered building components are the main parts used to build a steel structure, including columns, rafters, purlins, roofing sheets, wall panels, and connection systems. These parts work together to provide strength, stability, and protection from weather. A pre-engineered steel building is designed according to the size, location, and purpose of a project. Its main steel parts are manufactured before being transported to the site for assembly. This helps organise construction work and reduces the need for extensive steel fabrication at the site.
Explore the components of pre engineered building systems helps buyers compare materials, check quotations, and choose the right building for their business. The quality of the finished structure depends on proper engineering, suitable materials, and correct installation.
Published August 20, 2025
Quick Answer
What Are the Main Components of a Pre Engineered Building?
The main pre engineered building components include primary steel framing, secondary framing, roof and wall cladding, bracing, fasteners, insulation, and accessories. Primary framing supports the building, while secondary members hold the roof and wall panels. Cladding protects the structure from weather, and accessories such as gutters, doors, and ventilators make the building suitable for daily use.
Key takeaway
Primary steel framing includes columns and rafters that form the main structure and support the building's loads.
Secondary framing consists of purlins, girts, and eave struts that support the roof and wall panels.
Roofing and wall cladding protect the building from weather, while insulation and ventilation help maintain suitable indoor conditions.
Bracing, bolts, and connections help maintain structural stability and transfer loads safely through the building.
Gutters, flashings, doors, and other accessories improve drainage, weather protection, and everyday usability.
Component selection depends on project requirements, including building dimensions, location, structural loads, and intended use.
Before approving fabrication, review the engineering drawings, steel specifications, roofing details, connections, and project scope.
When comparing PEB manufacturers, check the quality of the proposed materials, engineering details, included services, and total project cost rather than choosing on price alone.
What Are the Main Components of a Pre Engineered Building?
1. Primary Steel Framing
Primary framing forms the main structure of a PEB building. It mainly consists of steel columns and rafters. Columns transfer loads to the foundation, while rafters support the roof and connect with the columns to form the main frame. These structural steel components determine the building's strength, height, and span. Their size and specifications depend on the building design, wind loads, roof loads, and other structural requirements.
When choosing a supplier, buyers should check the proposed frame design and steel specifications. The structure must be designed for its intended use rather than selected only on the basis of price.
2. Secondary Framing: Purlins and Girts
Secondary framing supports the roof and wall covering and connects it to the main steel frame.
Purlins support the roof sheets.
Girts support the wall panels.
Eave struts support the area where the roof meets the sidewalls.
These steel structural components help transfer loads to the main frame. Their size, spacing, and connections must match the building design and cladding requirements.
Buyers should check these details in the technical quotation because unsuitable members or incorrect spacing can affect the support provided to the roof and walls.
3. Roofing Sheets and Wall Cladding
Roofing sheets and wall panels protect the building from rain, wind, sunlight, and dust. They also affect indoor comfort, appearance, and maintenance.
Common options include profiled steel sheets, colour-coated sheets, and insulated sandwich panels. The right choice depends on the building's purpose, local weather, and insulation needs. During PEB building design, check the sheet thickness, coating quality, panel type, and fixing details. Proper installation and well-designed joints help reduce water leakage and maintenance problems.
4. Bracing and Connection Systems
Bracing helps keep the building stable against sideways forces, including wind loads. It may be installed in the roof and walls according to the structural design. Bolts, fasteners, base plates, and connection plates join the steel members and connect the columns to the foundation. These parts help transfer loads safely through the structure.
Although they may be smaller than the main frame, they are important to building performance. Their specifications and installation must follow the approved engineering drawings. Structural braces should never be removed or changed without approval from a qualified engineer.
5. Insulation and Ventilation
Insulation helps reduce heat transfer through the roof and walls, while ventilation allows air to move through the building. Both can improve indoor conditions when designed for the building's intended use.
The required system depends on the local climate, internal heat, moisture, and the activities carried out inside the building. These needs should be discussed during PEB engineering so that the panels, openings, and ventilation systems can be planned together.
6. Gutters, Flashings and Other Accessories
Accessories help protect the building and make it practical for everyday use. Gutters and downpipes carry rainwater away from the roof. Flashings cover roof edges and joints to help prevent water entry. Doors, windows, skylights, and canopies provide access and other useful features. Mezzanine floors can also be included when required and properly designed. These prefabricated building components should be included in the project plan from the beginning. Buyers should confirm which accessories are covered in the quotation to avoid unexpected costs later.
Pre Engineered Building Components and Their Functions
Each component of a pre engineered building has a specific role in the strength, stability, and daily use of the structure. Understanding these functions helps buyers check the building design and compare supplier quotations.
Building component
Main function
What buyers should check
Columns and rafters
Form the main frame and support structural loads
Steel specifications and approved design
Purlins and girts
Support roof sheets and wall panels
Member size, spacing, and connections
Roofing and wall cladding
Protect the building from weather
Sheet thickness, coating, and insulation
Bracing system
Help maintain structural stability
Design and connection details
Bolts and fasteners
Connect steel members and fix panels
Correct type, grade, and installation
Gutters and flashings
Direct rainwater and protect joints
Drainage and weatherproofing details
Insulation and ventilators
Help control heat transfer and air movement
Building use and ventilation requirements
The specifications of these components depend on the building's dimensions, location, structural loads, and intended use. Buyers should review the complete design instead of selecting individual parts only by price.
How Do Pre Engineered Building Components Work Together?
All components work as one connected system. Roof sheets transfer their loads to purlins, while wall panels are supported by girts. These members transfer loads to the main steel frames, which carry them through the connections to the foundations. Bracing helps the building remain stable.
This is why PEB building construction requires proper engineering, accurate drawings, and correct installation. The design must consider building dimensions, site conditions, structural loads, openings, drainage, and operational needs.
Good coordination between design, fabrication, and site installation helps reduce errors and ensures that the finished building matches the approved specifications.
What Should You Check Before PEB Fabrication Begins?
Before fabrication starts, confirm that the building design and project requirements have been finalised. Changes made after manufacturing begins can cause delays, extra costs, and material wastage.
Check the following points before approving fabrication:
Approved drawings: Confirm the building dimensions, column positions, roof layout, and openings.
Steel specifications: Review the specified steel grades, member sizes, and relevant material requirements.
Roofing and wall panels: Confirm sheet thickness, coatings, insulation, and fixing details.
Structural connections: Check the approved details for bolts, base plates, bracing, and other connections.
Accessories and drainage: Make sure gutters, downpipes, flashings, doors, and other required items are included.
Project scope: Confirm who is responsible for transportation, site erection, foundation work, and other services.
Also, discuss any machinery loads, overhead cranes, mezzanine floors, or future expansion plans with the engineering team before finalising the design. These requirements may affect the structure and should not be left until installation.
A clear scope of work and approved engineering drawings help the buyer and manufacturer work towards the same requirements throughout the project.
How Do You Choose the Right PEB Components and Manufacturer?
Before selecting a supplier, define your building size, location, intended use, and any special requirements. Then compare quotations using the same project scope.
Check the steel specifications, frame design, roofing and wall panels, connection details, protective coatings, insulation, and accessories. Also confirm whether design, fabrication, transportation, and erection are included in the quotation.
When comparing pre engineered building manufacturers, review their engineering process, fabrication quality, material documentation, and installation support. A clear quotation should explain what is included and identify any additional costs.
The right supplier should understand your requirements and offer a suitable design rather than simply quoting the lowest price.
A well-planned PEB project depends on accurate requirements, appropriate engineering, clearly defined specifications, and coordination between design, fabrication, and site erection.
Conclusion
Pre engineered building components work together to create a strong, stable, and useful steel building. Primary framing supports the structure, secondary members hold the roof and walls, and cladding, bracing, connections, and accessories complete the building.
Choosing the right components requires careful attention to the building's purpose, material quality, engineering, and total project cost.
